Solar Charge Controller | Victron | SmartSolar MPPT 100/20
Product Details
The Victron SmartSolar MPPT 100/20 is a rare three-voltage controller: it auto-detects and charges 12V, 24V, or 48V battery banks, making it the most versatile compact SmartSolar available. With a 100V PV input ceiling and 20A maximum charge current, it handles up to 290W at 12V, 580W at 24V, or 1,160W at a 48V system. Built-in Bluetooth and the VictronConnect app provide wireless configuration from your phone — no extra hardware required.
Key Features
- Ultra-fast MPPT tracking
- Built-in Bluetooth Smart
- VE.Direct port
- Load output with BatteryLife algorithm
- SafetyShield+ protection
- VE.Smart Networking
Technical Specifications
| Specification | Value |
|---|---|
| Max PV Open Circuit Voltage | 100V |
| Max Charge Current | 20A |
| System Voltage | 12/24/48V auto-select |
| Max PV Power (12V) | 290W |
| Max PV Power (24V) | 580W |
| Max PV Power (48V) | 1160W |
| Efficiency | Up to 98% |
| Bluetooth | Built-in |
| Enclosure | IP22 (connection area),IP43 (electronic components) |
| Dimensions | 100 x 113 x 131 mm |
| Weight | 0.65 kg |
Compatible Battery Types
Works with AGM, Gel, Flooded (wet cell), LiFePO4, and lithium-ion batteries. Battery type and absorption/float voltages are configurable via the VictronConnect app.
Use Cases
The 48V compatibility makes this controller future-proof for caravanners upgrading their electrical system. Run it now on a 12V setup and transition to 24V or 48V without replacing the controller.
Off-road tourers building 48V lithium systems will appreciate this unit's three-voltage auto-detect. It also includes a load output — connect a DC fridge directly with low-voltage disconnect to protect the battery.
Yacht owners planning a future upgrade to 48V house bank will find the 100/20-48V covers all bases. The compact enclosure fits neatly in electrical panels where space is at a premium.
Ideal for hybrid off-grid cabins where you want to start small and scale up. Begin on a 12V/200Ah battery bank and expand to 48V later — the controller transitions with the system.
App Control & Connectivity
All SmartSolar MPPT controllers feature built-in Bluetooth for wireless monitoring and configuration via the free VictronConnect app (iOS and Android). Adjust charge settings, view real-time solar data, and receive alerts — all without needing a laptop or additional hardware. For advanced monitoring, connect to a Victron GX device (Cerbo GX, Venus GX) for full system integration and remote access via VRM.
